• 0


  • 1/2.8” 2Megapixel progressive scan CMOS
  • Support H.264/MJPEG multiple code
  • 25/30fps@1080(1920×1080)
  • Support strong light suppression
  • Function control pane (l Support 3.5 inch LCD screen, Menu in Chinese and English?
  • Adjustable speed four gea?r 30yards ?60yards ?90yards ?120yards
  • 6mm ~22mm Varifocal lens
  • Effective distance?Within 20 M
  • Support ONVIF ,Support HKVISION? DAHUA? XM-EYE? World
  • Famous NVR
  • white light lamp: 42μ x 6PCS(The light brightness is adjustable?
  • Waterproof, IP66, DC12V/2A
Categories: ,


Image sensor1/2.8” 2Megapixel progressive scan WDR Sensor
Effective pixel1920(H) x 1080(V)
Electronic shutter speedAuto/Manual, 1/3(4)~1/100000s
Min. illumination0.01Lux/F1.4(Color); 0Lux/F1.4(white on)
S/N RatioMore than 50dB
Day/NightFull Color
Backlight compensationBLC / WDR(120dB)
Image SettingCompression, Brightness, Contrast, Mirroring, Sharpness, AWB, AES, AGC, BLC, Day/Night mode, WDR, Privacy Masking, Sunny/Night/Outdoor/Customized mode.
White balanceAuto/Sunny/Night/Outdoor/Customized
Gain control / Noise reductionAuto/Manual , 3D
Privacy maskingPrivacy Masking Up to 4 areas
Focal Length / Max. aperture6mm~22mm Varifocal Manual / F1.4
lens type / Mouse typeManual / Board-in Type
CompressionH.264/ MJPEG
Frame rate / Bit rate1080P/720P(1 ~ 25/30fps) / H.264: 32K bps~ 10Mbps
Ethernet / Security / ONVIFRJ-45 (10/100Base-T) / Password, IP Address Filtering, User Privileges / Supported
Smart phoneiPhone & Android
Power supply / Power consumptionDC12V/2A / <11.5W (with IR on, motorized lens working)
Working environmentWorking Environment -30°C~+60°C, Less than 95% RH
Ingress protection / HousingIp66 / Metal Body (Aluminum) with cable management bracket
Dimension / WeightDimension / Weight 390mm × 160mm× 155mm / 2.0kg
